| Tank Volume (Gallons) | Internal Dimensions (L x W x H in.) |
|---|---|
| 5.0 | 12.9 x 11.8 x 7.9 |
Combines sweep for cleaning uniformity with pulse to remove stubborn contaminants, degas fresh solutions, or for mixing and sample prep in the lab.
The microprocessor-controlled generator maintains constant ultrasonic power, sensing and adjusting for light or heavy loads in the tank. Digital operation ensures reproducible performance from run to run.
Select the cleaning time from 1-30 minutes. Or set the unit for continuous operation. In this mode you can stop the cleaning manually.
Eco Mode offers reduced-power gentle cleaning, quiet operation, and extends tank lifetime.
Set the cleaning temperature from 30°C to 80°C in increments of 5°C.
E Plus line models from EP60H to EP300H have a rear drain with a valve for easy emptying of the tank. The valve is located on the side of the tank for easy access.
Choose the easily operated Elmasonic E Plus for fast and thorough cleaning of a wide range of parts and instruments. Dynamic mode combines sweep frequency for uniform cleaning action with bursts of power to remove stubborn contaminants, quickly degas fresh cleaning solutions, or prepare lab samples. Eco mode offers quiet, gentle cleaning at reduced power. This economical product line is manufactured in Germany to the highest quality standards and is backed by a 2-year warranty from your purchase date.
Easy to use: set the timer and heater knobs and press the start key to begin cleaning. The Elmasonic E Plus is surprisingly quiet during operation.
The microprocessor-controlled generator maintains constant ultrasonic power, sensing and adjusting for light or heavy loads in the tank. Digital operation with power tracking ensures reproducible performance from run to run.
| Model | EP180H |
|---|---|
| Tank max. capacity | 5.0 gal |
| Tank internal dimensions L/W/D | 12.9 x 11.8 x 7.9 in |
| Heat | 30°C to 80°C |
| Drain | Equipped |
| Mains voltage (V~) | 115 |
| Ultrasonic frequency (kHz) | 37 |
| Model | Tank Volume (Gallons) | Internal Dimensions (L x W x H in.) |
|---|---|---|
| EP10 | 0.25 | 7.5 x 3.3 x 2.4 |
| EP10H | 0.25 | 7.5 x 3.3 x 2.4 |
| EP20 | 0.5 | 5.9 x 5.4 x 3.9 |
| EP20H | 0.5 | 5.9 x 5.4 x 3.9 |
| EP30 | 0.75 | 9.4 x 5.4 x 3.9 |
| EP30H | 0.75 | 9.4 x 5.4 x 3.9 |
| EP40H | 1.0 | 9.4 x 5.4 x 5.9 |
| EP60H | 1.5 | 11.8 x 5.9 x 5.9 |
| EP100H | 2.5 | 11.8 x 9.4 x 5.9 |
| EP120H | 3.5 | 11.8 x 9.4 x 7.9 |
| EP180H | 5.0 | 12.9 x 11.8 x 7.9 |
| EP300H | 7.5 | 19.9 x 11.8 x 7.9 |
Tell us your parts, cleaning chemistry, and cycle requirements. We'll confirm the right E Plus configuration for your application.
