The Elmasolvex VA is an automated tabletop system designed for solvent-based cleaning of very small, precision parts. It combines ultrasonic cleaning with vacuum-assisted processing to help clean, rinse, and dry parts in a controlled, closed chamber.
Solvent vapors can be routed to your facility exhaust system, or captured using an optional activated carbon filtration unit.
This model is intended for use with appropriate solvents; verify solvent compatibility and safety requirements for your process.
| Accessory | What it’s for |
|---|---|
|
VA basket set (5), 80 mm, stainless electropolished
SKU 1055836
|
Holds small parts securely during solvent cleaning cycles; electropolished finish for easier cleaning. |
|
VA basket set (3), 64 mm, stainless
SKU 1052351
|
Compact basket set for smaller components and tighter loads. |
|
VA activated carbon unit
SKU 1053376
|
Optional filtration module to capture solvent vapors/residues when facility exhaust routing isn’t used. |
| Effective ultrasonic power | 50 W (adjustable 30–100%) |
| Cleaning ultrasonic frequency | 40 kHz |
| Rinsing ultrasonic frequency | 80 kHz |
| Basket rotation (clean/rinse) | 1–20 rpm |
| Cycle programs | 6 fixed, 12 user-definable |
| Dimensions | 24 in D × 24 in H |
| Weight | 86 lb |
For full details and process suitability, contact Tovatech or review the documentation for your solvent and application.
Tell us your solvent type, contamination, and safety requirements. We'll confirm whether Elmasolvex is the right fit for your application.
